8.4.2 Power Down Options

A global power down mode can be enabled via SPI as well as using the power down pin (PDN/SYNC). There is an internal pull-down 21 kΩ resistor on the PDN/SYNC input pin and the pin is active high - so the pin needs to be pulled high externally to enter global power down mode.

The SPI register map provides the capability to enable/disable individual blocks directly or via PDN pin mask in order to trade off power consumption vs wake up time as shown in Table 8-10.

GUID-20200909-CA0I-SHMP-HKS0-D6XKVD84HLJ7-low.gifFigure 8-49 Power Down Configurations
Table 8-10 Overview of Power Down Options
Function/ RegisterPDN
via SPI		Mask for
Global PDN		Feature - DefaultPower
Impact		Wake-up
time		Comment
ADCYes-EnabledBoth ADC channels are included in Global PDN automatically
Reference gain amplifierYesYesEnabled~ 0.4 mA~3 usShould only be powered down in power down state.
Internal 1.2V referenceYesExternal ref~ 1-3.5 mA~3 msInternal/external reference selection is available through SPI and REFBUF pin.
Clock bufferYesDifferential clock~ 1 mAn/aSingle ended clock input saves ~ 1mA compared to differential.
Some programmability is available through the REFBUF pin.
Output interface driversYes-Enabledvariesn/aDepending on output interface mode, unused output drivers can be powered down for maximum power savings
Decimation filterYes-Disabledsee electrical tablen/a
