7.4.2.4.2 Software Mode Channel Selection

In software mode, the channels for conversion are selected by programming the relevant channel register. On power-up or after a reset, the default channels selected for conversion are channel AIN_0A and channel AIN_0B. See Figure 7-13, Figure 7-14, and Figure 7-15 for additional details regarding the channel selection.

GUID-56797CDB-B816-41DE-84B4-69E9029512E5-low.gifFigure 7-13 Software Serial Mode Channel Conversion Setting
GUID-F2D7580D-2A74-4C74-9CFF-969CC9D1C374-low.gifFigure 7-14 Software Parallel Byte Mode Channel Conversion Setting
GUID-B8F78B83-2B3C-4F01-A86C-E63E7F4D0BB4-low.gifFigure 7-15 Software Parallel Mode Channel Conversion Setting
