10.1.2 Error Amplifier and Compensation

Figure 10-3 shows a Type-II compensator using a transconductance error amplifier (EA). The dominant pole of the EA open-loop gain is set by the EA output resistance, RO-EA, and effective bandwidth-limiting capacitance, CBW, as shown in Equation 28.

Equation 28. GUID-B6866D7B-3EA2-4253-8D85-6FB80BC81BEA-low.gif

The EA high-frequency pole is neglected in Equation 28. The compensator transfer function from output voltage to COMP node, including the gain contribution from the (internal or external) feedback resistor network, is calculated in Equation 29.

Equation 29. GUID-C156DE60-6CCE-4154-AD51-2B6C8E792F45-low.gif

where

  • VREF is the feedback voltage reference of 0.6 V.
  • gm is the EA gain transconductance of 1200 µS.
  • RO-EA is the error amplifier output impedance of 64 MΩ.
Equation 30. GUID-29DB74F9-C32C-4CC5-A569-493C39B52F6E-low.gif
Equation 31. GUID-3CB99734-6E57-4170-AFAC-FC24ED75EC0C-low.gif
Equation 32. GUID-2E7A4756-CFE1-4327-819B-DCFF41D483EB-low.gif

The EA compensation components create a pole close to the origin, a zero, and a high-frequency pole. Typically, RCOMP << RO-EA and CCOMP >> CBW and CHF, so the approximations are valid.

Figure 10-3 Error Amplifier and Compensation Network
