9.2.2.5 Current Sense (RS)

Based on the assumptions that 20% of current limit margin (MCL = 1.2), 80% estimated efficiency (Eff = 0.8) at full load and no RSL populated, RS is calculated using Equation 22 and Equation 23.

Equation 22. GUID-F11D95A9-B171-4D90-9AA1-2BE5D8E0EC08-low.gif
Equation 23. GUID-E9B935B0-0DF6-48DF-95B4-9BC8758AD331-low.gif

Substitute FSW_RT for FSYNC if the clock synchronization is not used.

A standard value of 7 mΩ is chosen for RS. A low-ESL resistor is recommended to minimize the error caused by the ESL.
