9.2.2.8 Loop Compensation Component Selection and Maximum ESR

Based on Equation 18, CCOMP is calculated as follows:

Equation 34. GUID-77F7C17F-1089-4DBD-A897-1A9E7D73E381-low.gif
Equation 35. GUID-32B438BF-C59E-4673-90CE-1CB19E5765B9-low.gif

By selecting CCOMP following Equation 34, the typical phase margin is set to 90⁰ and the loop response is overdamped. In this example, FZ_EA is placed at three times higher frequency than FLP to have lower phase margin but faster settling time (K2 = 3, target FZ_EA is 1.02 kHz). Recommended range of FZ_EA is from 1 × FLP to 4 × FLP (1 ≤ K2 ≤ 4). Practical crossover frequency will vary with K2 with a range of 0.5 × FCROSS to 1.0 × FCROSS.

Equation 36. GUID-421FD288-230F-4B2F-AEF7-75EA31803814-low.gif

A standard value of 33 nF is chosen for CCOMP.

RCOMP is selected to set the error amplifier zero at 1.02 kHz.

Equation 37. GUID-020305E8-5FC6-452B-91BB-928EB71B242A-low.gif

A standard value of 4.64 kΩ is chosen for RCOMP.

CHF is usually used to create a pole at high frequency (FP_EA) to cancel FZ_ESR. By using a small ESR capacitor, which can place FZ_ESR greater than 10 × FCROSS, the output capacitor ESR would not affect the loop stability. The maximum ESR, which does not affect the loop response, is calculated using Equation 38.

Equation 38. ;GUID-9E8FC73C-B968-42C4-B58A-879AA7A819F8-low.gif
