6 Parameter Measurement Information

MAX3221E Driver Slew Rate
A. CL includes probe and jig capacitance.
B. The pulse generator has the following characteristics: PRR = 250kbps, ZO = 50Ω, 50% duty cycle, tr ≤ 10ns, tf ≤ 10ns.
Figure 6-1 Driver Slew Rate
MAX3221E Driver Pulse Skew
A. CL includes probe and jig capacitance.
B. The pulse generator has the following characteristics: PRR = 250kbps, ZO = 50Ω, 50% duty cycle, tr ≤ 10ns, tf ≤ 10ns.
Figure 6-2 Driver Pulse Skew
MAX3221E Receiver Propagation Delay Times
A. CL includes probe and jig capacitance.
B. The pulse generator has the following characteristics: ZO = 50Ω, 50% duty cycle, tr ≤ 10ns, tf ≤ 10ns.
Figure 6-3 Receiver Propagation Delay Times
MAX3221E Receiver Enable and Disable Times
A. CL includes probe and jig capacitance.
B. The pulse generator has the following characteristics: ZO = 50Ω, 50% duty cycle, tr ≤ 10ns, tf ≤ 10ns.
C. tPLZ and tPHZ are the same as tdis.
D. tPZL and tPZH are the same as ten.
Figure 6-4 Receiver Enable and Disable Times
MAX3221E INVALID Propagation Delay Times and Driver Enabling TimeFigure 6-5 INVALID Propagation Delay Times and Driver Enabling Time
