7 Parameter Measurement Information

Phase relationships between waveforms were chosen arbitrarily for the examples listed in the following table. All input pulses are supplied by generators having the following characteristics: PRR ≤ 1 MHz, ZO = 50 Ω, tt < 2.5 ns.

The outputs are measured individually with one input transition per measurement.

TEST S1 RL CL ΔV VCC
tPLZ, tPZL CLOSED 1 kΩ 15 pF, 50 pF 0.15 V ≤ 2.5 V
tPLZ, tPZL CLOSED 1 kΩ 15 pF, 50 pF 0.3 V > 2.5 V

(1) CL includes probe and test-fixture capacitance.
Figure 7-1 Load Circuit for Open-Drain Outputs
GUID-20230721-SS0I-VJQB-BMGP-K0S1JW76FHMX-low.svg
Noise values measured with all other outputs simultaneously switching.
Figure 7-3 Voltage Waveforms, Noise
(1) tPLZ is the same as tdis.
(2) tPZL is the same as ten.
Figure 7-2 Voltage Waveforms Propagation Delays
