10.2.2.2 Application Curves

TAS6424M-Q1 D033_SLOS870.gif
1 kHz PVDD = 14.4 V
Figure 83. THD vs Output Power
TAS6424M-Q1 D031_SLOS870.gif
1 W PVDD = 14.4 V
Figure 84. Frequency Response
