10.2.2.1 Connections on Unused Channels

On unused channels, it is recommended to ground the SENx pin and leave the GATx pin open. DRAINx pins can be grounded or left open (leaving open may slightly reduce power consumption). Figure 10-2 shows an example of an unused PORT2.

GUID-50EB220D-0684-405C-B582-9FE11CB03BCC-low.gifFigure 10-2 Unused PORT2 Connections
