4.21 Typical Characteristics

TPS659037 D010_SWCS095.gif
VI = 3.8 V ƒS = 2.2 MHz
Figure 4-4 SMPS Efficiency for Multi-Phase
Eco-mode
TPS659037 D008_SWCS095.gif
VI = 3.8 V ƒS = 2.2 MHz
Figure 4-6 SMPS Efficiency for 6-A Multi-Phase
PWM Mode
TPS659037 D006_SWCS095.gif
VI = 3.8 V ƒS = 2.2 MHz
Figure 4-8 SMPS Efficiency for 1-A Single-Phase
Eco-mode
TPS659037 D004_SWCS095.gif
VI = 3.8 V ƒS = 2.2 MHz
Figure 4-10 SMPS Efficiency for 2-A Single-Phase
Eco-ode
TPS659037 D002_SWCS095.gif
VI = 3.8 V ƒS = 2.2 MHz
Figure 4-12 SMPS Efficiency for 3-A Single-Phase
Eco-mode
TPS659037 D009_SWCS095.gif
VI = 3.8 V ƒS = 2.2 MHz
Figure 4-5 SMPS Efficiency for 4-A Multi-Phase
PWM Mode
TPS659037 D007_SWCS095.gif
VI = 3.8 V ƒS = 2.2 MHz
Figure 4-7 SMPS Efficiency for 9-A Multi-Phase
PWM Mode
TPS659037 D005_SWCS095.gif
VI = 3.8 V ƒS = 2.2 MHz
Figure 4-9 SMPS Efficiency for 1-A Single-Phase
PWM Mode
TPS659037 D003_SWCS095.gif
VI = 3.8 V ƒS = 2.2 MHz
Figure 4-11 SMPS Efficiency for 2-A Single-Phase
PWM Mode
TPS659037 D001_SWCS095.gif
VI = 3.8 V ƒS = 2.2 MHz
Figure 4-13 SMPS Efficiency for 3-A Single-Phase
PWM Mode
