5.10 Typical Characteristics

Typical values at 25°C, AIN = -1 dBFS, FIN = 347 MHz, FS = 1300 MSPS, High power mode, FG calibration, JMODE 0, CPLL off, CPLLREF = 50 MHz and VA11Q and VCLK11 noise suppression on when CPLL on, nominal supply voltages, unless otherwise noted. SNR results exclude DC, HD2 to HD9; SINAD, ENOB, and SFDR results exclude DC.

ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 DNL vs Code
Figure 5-1 DNL vs Code
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Input Fullscale vs Input Frequency
Relative to 0Hz
Figure 5-3 Input Fullscale vs Input Frequency
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Tone FFT at 497 MHz and -1 dBFS
High Power Mode
Figure 5-5 Single Tone FFT at 497 MHz and -1 dBFS
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Tone FFT at 1497 MHz and -1 dBFS
High Power Mode
Figure 5-7 Single Tone FFT at 1497 MHz and -1 dBFS
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Tone FFT at 2697 MHz and -1 dBFS
High Power Mode
Figure 5-9 Single Tone FFT at 2697 MHz and -1 dBFS
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Tone FFT at 99.997 MHz and -1 dBFS
FS = 1000MSPS, Low Power Mode
Figure 5-11 Single Tone FFT at 99.997 MHz and -1 dBFS
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Tone FFT at 1197 MHz and -1 dBFS
FS = 1000MSPS, Low Power Mode
Figure 5-13 Single Tone FFT at 1197 MHz and -1 dBFS
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SFDR vs Input Frequency
Figure 5-15 SFDR vs Input Frequency
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SINAD vs Input Frequency
Figure 5-17 SINAD vs Input Frequency
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 HD2 vs Input Frequency
Figure 5-19 HD2 vs Input Frequency
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SFDR vs Sample Rate
Figure 5-21 SFDR vs Sample Rate
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SINAD vs Sample Rate
Figure 5-23 SINAD vs Sample Rate
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SFDR vs Sample Rate
FS = 1000MSPS, Low Power Mode
Figure 5-25 SFDR vs Sample Rate
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SINAD vs Sample Rate
FS = 1000MSPS, Low Power Mode
Figure 5-27 SINAD vs Sample Rate
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SFDR vs Input Amplitude
Figure 5-29 SFDR vs Input Amplitude
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SFDR vs Input Amplitude
FS = 1000MSPS, FIN = 100MHz,Low Power Mode
Figure 5-31 SFDR vs Input Amplitude
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SFDR vs Clock Amplitude
Figure 5-33 SFDR vs Clock Amplitude
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SNR, SFDR and SINAD vs Temperature
FIN = 997 MHz
Figure 5-35 SNR, SFDR and SINAD vs Temperature
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SINAD vs Temperature and Calibration Mode
FIN = 997 MHz, FG25°C means calibration at 25°C and held across temperature
Figure 5-37 SINAD vs Temperature and Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SFDR vs Temperature and Calibration Mode
FIN = 997 MHz, FG25°C means calibration at 25°C and held across temperature
Figure 5-39 SFDR vs Temperature and Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SINAD vs Temperature and Calibration Mode
Low Power Mode, FIN = 347 MHz, FG25°C means calibration at 25°C and held across temperature
Figure 5-41 SINAD vs Temperature and Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SFDR vs Temperature and Calibration Mode
Low Power Mode, FIN = 347 MHz, FG25°C means calibration at 25°C and held across temperature
Figure 5-43 SFDR vs Temperature and Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 HD2, HD3 and Worst non-HD Spur vs Supply Voltage
FIN = 347 MHz
Figure 5-45 HD2, HD3 and Worst non-HD Spur vs Supply Voltage
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 HD2, HD3 and Worst non-HD Spur vs Supply Voltage
Low Power Mode, FIN = 347 MHz, FS = 1000MSPS
Figure 5-47 HD2, HD3 and Worst non-HD Spur vs Supply Voltage
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Two Tone FFT at 348 MHz Center
10 MHz Tone Spacing
Figure 5-49 Two Tone FFT at 348 MHz Center
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Two Tone FFT at 998 MHz Center
10 MHz Tone Spacing
Figure 5-51 Two Tone FFT at 998 MHz Center
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Two Tone FFT at 2698 MHz Center
10 MHz Tone Spacing
Figure 5-53 Two Tone FFT at 2698 MHz Center
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Two Tone FFT at 348 MHz Center
Low Power Mode, FS = 1000 MSPS, 10 MHz Tone Spacing
Figure 5-55 Two Tone FFT at 348 MHz Center
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 IMD3 vs Input Frequency
10 MHz Tone Spacing
Figure 5-57 IMD3 vs Input Frequency
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Crosstalk to Channel A vs FIN
Figure 5-59 Crosstalk to Channel A vs FIN
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SFDR vs Reference Clock Frequency
CPLL On, FIN = 397MHz
Figure 5-61 SFDR vs Reference Clock Frequency
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SNR vs Input Frequency and CPLL
FS = 1300MSPS, High Power Mode
Figure 5-63 SNR vs Input Frequency and CPLL
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SFDR vs Input Frequency and CPLL
FS = 1000MSPS
Figure 5-65 SFDR vs Input Frequency and CPLL
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SINAD vs Input Frequency and CPLL
FS = 1000MSPS
Figure 5-67 SINAD vs Input Frequency and CPLL
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SNR vs Input Frequency, CPLL and Input Amplitude
FS = 1300MSPS, High Power Mode
Figure 5-69 SNR vs Input Frequency, CPLL and Input Amplitude
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SINAD vs Input Frequency, CPLL and Input Amplitude
FS = 1300MSPS, High Power Mode
Figure 5-71 SINAD vs Input Frequency, CPLL and Input Amplitude
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 HD2 vs Input Frequency, CPLL and Input Amplitude
FS = 1300MSPS, High Power Mode
Figure 5-73 HD2 vs Input Frequency, CPLL and Input Amplitude
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SNR vs Input Frequency, CPLL and Input Amplitude
FS = 1000MSPS, Low Power Mode
Figure 5-75 SNR vs Input Frequency, CPLL and Input Amplitude
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SINAD vs Input Frequency, CPLL and Input Amplitude
FS = 1000MSPS, Low Power Mode
Figure 5-77 SINAD vs Input Frequency, CPLL and Input Amplitude
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 HD2 vs Input Frequency, CPLL and Input Amplitude
FS = 1000MSPS, Low Power Mode
Figure 5-79 HD2 vs Input Frequency, CPLL and Input Amplitude
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Quad Channel, Power Dissipation vs FS for JMODES 0 - 3
Figure 5-81 Quad Channel, Power Dissipation vs FS for JMODES 0 - 3
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Quad Channel, Power Dissipation vs FS for JMODES 8 - 11
Figure 5-83 Quad Channel, Power Dissipation vs FS for JMODES 8 - 11
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Quad Channel, IVA19 vs FS
Independent of JMODE
Figure 5-85 Quad Channel, IVA19 vs FS
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Quad Channel, IVD11 vs FS and JMODE 0 - 3
independent of power mode
Figure 5-87 Quad Channel, IVD11 vs FS and JMODE 0 - 3
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Quad Channel, IVD11 vs FS and JMODE 8 - 11
independent of power mode
Figure 5-89 Quad Channel, IVD11 vs FS and JMODE 8 - 11
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Dual Channel, Power Dissipation vs FS for JMODES 0 - 3
Figure 5-91 Dual Channel, Power Dissipation vs FS for JMODES 0 - 3
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Dual Channel, Power Dissipation vs FS for JMODES 8 - 11
Figure 5-93 Dual Channel, Power Dissipation vs FS for JMODES 8 - 11
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Dual Channel, IVA19 vs FS
Independent of JMODE
Figure 5-95 Dual Channel, IVA19 vs FS
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Dual Channel, IVD11 vs FS and JMODE 0 - 3
independent of power mode
Figure 5-97 Dual Channel, IVD11 vs FS and JMODE 0 - 3
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Dual Channel, IVD11 vs FS and JMODE 8 - 11
independent of power mode
Figure 5-99 Dual Channel, IVD11 vs FS and JMODE 8 - 11
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Channel, Power Dissipation vs FS for JMODES 0 - 3
Figure 5-101 Single Channel, Power Dissipation vs FS for JMODES 0 - 3
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Channel, Power Dissipation vs FS for JMODES 8 - 11
Figure 5-103 Single Channel, Power Dissipation vs FS for JMODES 8 - 11
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Channel, IVA19 vs FS
Independent of JMODE
Figure 5-105 Single Channel, IVA19 vs FS
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Channel, IVD11 vs FS and JMODE 0 - 3
independent of power mode
Figure 5-107 Single Channel, IVD11 vs FS and JMODE 0 - 3
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Channel, IVD11 vs FS and JMODE 8 - 11
independent of power mode
Figure 5-109 Single Channel, IVD11 vs FS and JMODE 8 - 11
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Quad Channel, Power Dissipation Change with Calibration Mode
Difference to foreground calibration, JMODE independent
Figure 5-111 Quad Channel, Power Dissipation Change with Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Channel, Power Dissipation Change with Calibration Mode
Difference to foreground calibration, JMODE independent
Figure 5-113 Single Channel, Power Dissipation Change with Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Dual Channel, IVA19 Change with Calibration Mode
Difference to foreground calibration, JMODE independent
Figure 5-115 Dual Channel, IVA19 Change with Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Quad Channel, IVA11 Change with Calibration Mode
Difference to foreground calibration, JMODE independent
Figure 5-117 Quad Channel, IVA11 Change with Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Channel, IVA11 Change with Calibration Mode
Difference to foreground calibration, JMODE independent
Figure 5-119 Single Channel, IVA11 Change with Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Dual Channel, IVD11 Change with Calibration Mode
Difference to foreground calibration, JMODE independent
Figure 5-121 Dual Channel, IVD11 Change with Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Quad Channel, Power Dissipation vs Temperature
Figure 5-123 Quad Channel, Power Dissipation vs Temperature
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Channel, Power Dissipation vs Temperature
Figure 5-125 Single Channel, Power Dissipation vs Temperature
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Background Calibration Core Transition (AC Signal)
Figure 5-127 Background Calibration Core Transition (AC Signal)
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Background Calibration Core Transition (DC Signal)
Figure 5-129 Background Calibration Core Transition (DC Signal)
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 INL vs Code
Figure 5-2 INL vs Code
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Tone FFT at 347 MHz and -1 dBFS
High Power Mode
Figure 5-4 Single Tone FFT at 347 MHz and -1 dBFS
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Tone FFT at 997 MHz and -1 dBFS
High Power Mode
Figure 5-6 Single Tone FFT at 997 MHz and -1 dBFS
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Tone FFT at 1797 MHz and -1 dBFS
High Power Mode
Figure 5-8 Single Tone FFT at 1797 MHz and -1 dBFS
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Tone FFT at 3497 MHz and -1 dBFS
High Power Mode
Figure 5-10 Single Tone FFT at 3497 MHz and -1 dBFS
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Tone FFT at 347 MHz and -1 dBFS
FS = 1000MSPS, Low Power Mode
Figure 5-12 Single Tone FFT at 347 MHz and -1 dBFS
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Tone FFT at 1797 MHz and -1 dBFS
FS = 1000MSPS, Low Power Mode
Figure 5-14 Single Tone FFT at 1797 MHz and -1 dBFS
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SNR vs Input Frequency
Figure 5-16 SNR vs Input Frequency
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 ENOB vs Input Frequency
Figure 5-18 ENOB vs Input Frequency
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 HD3 vs Input Frequency
Figure 5-20 HD3 vs Input Frequency
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SNR vs Sample Rate
Figure 5-22 SNR vs Sample Rate
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 ENOB vs Sample Rate
Figure 5-24 ENOB vs Sample Rate
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SNR vs Sample Rate
FS = 1000MSPS, Low Power Mode
Figure 5-26 SNR vs Sample Rate
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 ENOB vs Sample Rate
FS = 1000MSPS, Low Power Mode
Figure 5-28 ENOB vs Sample Rate
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SNR vs Input Amplitude
Figure 5-30 SNR vs Input Amplitude
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SNR vs Input Amplitude
FS = 1000MSPS, FIN = 100MHz, Low Power Mode
Figure 5-32 SNR vs Input Amplitude
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SNR vs Clock Amplitude
Figure 5-34 SNR vs Clock Amplitude
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 HD2, HD3 and worst non-HD Spur vs Temperature
FIN = 997 MHz
Figure 5-36 HD2, HD3 and worst non-HD Spur vs Temperature
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 ENOB vs Temperature and Calibration Mode
FIN = 997 MHz, FG25°C means calibration at 25°C and held across temperature
Figure 5-38 ENOB vs Temperature and Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SNR vs Temperature and Calibration Mode
Low Power Mode, FIN = 347 MHz, FG25°C means calibration at 25°C and held across temperature
Figure 5-40 SNR vs Temperature and Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 ENOB vs Temperature and Calibration Mode
Low Power Mode, FIN = 347 MHz, FG25°C means calibration at 25°C and held across temperature
Figure 5-42 ENOB vs Temperature and Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SNR, SFDR and SINAD vs Supply Voltage
FIN = 347 MHz
Figure 5-44 SNR, SFDR and SINAD vs Supply Voltage
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SNR, SFDR and SINAD vs Supply Voltage
Low Power Mode, FIN = 347 MHz, FS = 1000MSPS
Figure 5-46 SNR, SFDR and SINAD vs Supply Voltage
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Two Tone FFT at 95.07 MHz Center
10 MHz Tone Spacing
Figure 5-48 Two Tone FFT at 95.07 MHz Center
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Two Tone FFT at 498 MHz Center
10 MHz Tone Spacing
Figure 5-50 Two Tone FFT at 498 MHz Center
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Two Tone FFT at 1798 MHz Center
10 MHz Tone Spacing
Figure 5-52 Two Tone FFT at 1798 MHz Center
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Two Tone FFT at 95.07 MHz Center
Low Power Mode, FS = 1000 MSPS, 10 MHz Tone Spacing
Figure 5-54 Two Tone FFT at 95.07 MHz Center
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Two Tone FFT at 998 MHz Center
Low Power Mode, FS = 1000 MSPS, 10 MHz Tone Spacing
Figure 5-56 Two Tone FFT at 998 MHz Center
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 IMD3 vs Input Frequency
Low Power Mode, FS = 1000 MSPS, 10 MHz Tone Spacing
Figure 5-58 IMD3 vs Input Frequency
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Crosstalk to Channel B vs FIN
Figure 5-60 Crosstalk to Channel B vs FIN
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SFDR vs Input Frequency and CPLL
FS = 1300MSPS, High Power Mode
Figure 5-62 SFDR vs Input Frequency and CPLL
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 ENOB vs Input Frequency and CPLL
FS = 1300MSPS, High Power Mode
Figure 5-64 ENOB vs Input Frequency and CPLL
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SNR vs Input Frequency and CPLL
FS = 1000MSPS
Figure 5-66 SNR vs Input Frequency and CPLL
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 ENOB vs Input Frequency and CPLL
FS = 1000MSPS
Figure 5-68 ENOB vs Input Frequency and CPLL
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SFDR vs Input Frequency, CPLL and Input Amplitude
FS = 1300MSPS, High Power Mode
Figure 5-70 SFDR vs Input Frequency, CPLL and Input Amplitude
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 ENOB vs Input Frequency, CPLL and Input Amplitude
FS = 1300MSPS, High Power Mode
Figure 5-72 ENOB vs Input Frequency, CPLL and Input Amplitude
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 HD3 vs Input Frequency, CPLL and Input Amplitude
FS = 1300MSPS, High Power Mode
Figure 5-74 HD3 vs Input Frequency, CPLL and Input Amplitude
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 SFDR vs Input Frequency, CPLL and Input Amplitude
FS = 1000MSPS, Low Power Mode
Figure 5-76 SFDR vs Input Frequency, CPLL and Input Amplitude
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 ENOB vs Input Frequency, CPLL and Input Amplitude
FS = 1000MSPS, Low Power Mode
Figure 5-78 ENOB vs Input Frequency, CPLL and Input Amplitude
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 HD3 vs Input Frequency, CPLL and Input Amplitude
FS = 1000MSPS, Low Power Mode
Figure 5-80 HD3 vs Input Frequency, CPLL and Input Amplitude
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Quad Channel, Power Dissipation vs FS for JMODES 4 - 7
Figure 5-82 Quad Channel, Power Dissipation vs FS for JMODES 4 - 7
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Quad Channel, Power Dissipation vs FS for JMODES 12 - 15
Figure 5-84 Quad Channel, Power Dissipation vs FS for JMODES 12 - 15
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Quad Channel, IVA11 vs FS
Independent of JMODE
Figure 5-86 Quad Channel, IVA11 vs FS
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Quad Channel, IVD11 vs FS and JMODE 4 - 7
independent of power mode
Figure 5-88 Quad Channel, IVD11 vs FS and JMODE 4 - 7
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Quad Channel, IVD11 vs FS and JMODE 12 - 15
independent of power mode
Figure 5-90 Quad Channel, IVD11 vs FS and JMODE 12 - 15
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Dual Channel, Power Dissipation vs FS for JMODES 4 - 7
Figure 5-92 Dual Channel, Power Dissipation vs FS for JMODES 4 - 7
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Dual Channel, Power Dissipation vs FS for JMODES 12 - 15
Figure 5-94 Dual Channel, Power Dissipation vs FS for JMODES 12 - 15
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Dual Channel, IVA11 vs FS
Independent of JMODE
Figure 5-96 Dual Channel, IVA11 vs FS
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Dual Channel, IVD11 vs FS and JMODE 4 - 7
independent of power mode
Figure 5-98 Dual Channel, IVD11 vs FS and JMODE 4 - 7
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Dual Channel, IVD11 vs FS and JMODE 12 - 15
independent of power mode
Figure 5-100 Dual Channel, IVD11 vs FS and JMODE 12 - 15
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Channel, Power Dissipation vs FS for JMODES 4 - 7
Figure 5-102 Single Channel, Power Dissipation vs FS for JMODES 4 - 7
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Channel, Power Dissipation vs FS for JMODES 12 - 15
Figure 5-104 Single Channel, Power Dissipation vs FS for JMODES 12 - 15
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Channel, IVA11 vs FS
Independent of JMODE
Figure 5-106 Single Channel, IVA11 vs FS
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Channel, IVD11 vs FS and JMODE 4 - 7
independent of power mode
Figure 5-108 Single Channel, IVD11 vs FS and JMODE 4 - 7
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Channel, IVD11 vs FS and JMODE 12 - 15
independent of power mode
Figure 5-110 Single Channel, IVD11 vs FS and JMODE 12 - 15
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Dual Channel, Power Dissipation Change with Calibration Mode
Difference to foreground calibration, JMODE independent
Figure 5-112 Dual Channel, Power Dissipation Change with Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Quad Channel, IVA19 Change with Calibration Mode
Difference to foreground calibration, JMODE independent
Figure 5-114 Quad Channel, IVA19 Change with Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Single Channel, IVA19 Change with Calibration Mode
Difference to foreground calibration, JMODE independent
Figure 5-116 Single Channel, IVA19 Change with Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Dual Channel, IVA11 Change with Calibration Mode
Difference to foreground calibration, JMODE independent
Figure 5-118 Dual Channel, IVA11 Change with Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Quad Channel, IVD11 Change with Calibration Mode
Difference to foreground calibration, JMODE independent
Figure 5-120 Quad Channel, IVD11 Change with Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Dual Channel, IVD11 Change with Calibration Mode
Difference to foreground calibration, JMODE independent
Figure 5-122 Dual Channel, IVD11 Change with Calibration Mode
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Dual Channel, Power Dissipation vs Temperature
Figure 5-124 Dual Channel, Power Dissipation vs Temperature
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Background Calibration Core Transition (midscale voltage)
Figure 5-126 Background Calibration Core Transition (midscale voltage)
ADC09QJ1300 ADC09DJ1300 ADC09SJ1300 Background Calibration Core Transition (AC Signal Zoomed)
Figure 5-128 Background Calibration Core Transition (AC Signal Zoomed)
