9.2.3 Application Curves

TPS2388 typ_01_Startup_Valid_PD_CLASS_0_LUSC25.png
Figure 72. Startup With Valid PD (25 kΩ and 0.1 μF), Class 0
TPS2388 typ_03_Detection_Invalid_PD_LUSC25.png
Figure 74. Detection With Invalid PD (15 kΩ and 0.1 μF)
TPS2388 typ_05_Detection_Invalid_PD_25_kohm_LUSC25.png
Figure 76. Detection With Invalid PD (25 kΩ and 10 μF)
TPS2388 typ_07_Powering_Up_100_microF_Load_LUSC25.png
Figure 78. Powering Up into a 100-μF Load
TPS2388 typ_09_All_Ports_Fast_Shutdown_OSS_Input_LUSC25.png
Figure 80. All Ports Fast Shutdown from OSS Input
TPS2388 typ_11_Overcurrent_ICUT_Timeout_LUSC25.png
Figure 82. Overcurrent (ICUT) Timeout
TPS2388 typ_13_Rapid_Response_1_ohm_Short_PoE_LUSC25.png
Figure 84. Rapid Response to a 1-Ω Short - PoE+ Mode
TPS2388 typ_15_Response_25_ohm_Load_PoE_LUSC25.png
Figure 86. Response to a 25-Ω Load - PoE+ Mode
TPS2388 typ_17_Current_Limit_15_ms_Timeout_PoE_45_ohm_Load_LUSC25.png
Figure 88. Current Limit 15-ms Timeout - PoE+ Mode, 45-Ω Load
TPS2388 typ_19_Current_Limit_Timeout_Restart_Delay_LUSC25.png
Figure 90. Current Limit Timeout Restart Delay
TPS2388 app_01_LUSC24.gifFigure 92. Detection With Open Circuit
TPS2388 app_03_LUSC24.gifFigure 94. 2-Event Class and Port Turn On
TPS2388 typ_02_Startup_Valid_PD_CLASS_3_LUSC25.png
Figure 73. Startup With Valid PD (25 kΩ and 0.1 μF), Class 3
TPS2388 typ_04_Detection_Invalid_PD_open_cir_LUSC25.png
Figure 75. Detection With Invalid PD (Open Circuit)
TPS2388 typ_06_2_Event_Class_Startup_Valid_PD_LUSC25.png
Figure 77. 2-Event Class and Startup With Valid PD
TPS2388 typ_08_All_Ports_Power_On_TPON_Bit_Set_LUSC25.png
Figure 79. All Ports Power-On With TPON Bit Set
TPS2388 typ_10_Ports_Fast_Shutdown_3_bit_OSS_Input_LUSC25.png
Figure 81. Ports Fast Shutdown from 3-Bit OSS Input
TPS2388 typ_12_Rapid_Response_1_ohm_Short_802.3af_LUSC25.png
Figure 83. Rapid Response to a 1-Ω Short - 802.3af Mode
TPS2388 typ_14_Response_50_ohm_Load_802.3af_LUSC25.png
Figure 85. Response to a 50-Ω Load - 802.3af Mode
TPS2388 typ_16_Current_Limit_Timeout_802.3af_85_ohm_LUSC25.png
Figure 87. Current Limit Timeout - 802.3af Mode, 85-Ω Load
TPS2388 typ_18_Inrush_Fault_Timeout_100_ohm_Load_LUSC25.png
Figure 89. Inrush Fault Timeout - 100-Ω Load
TPS2388 typ_20_Response_to_8_to_6_mA_Load_DC_Disconnect_LUSC25.png
Figure 91. Response to 8-mA to 6-mA Load, DC Disconnect Enabled
TPS2388 app_02_LUSC24.gifFigure 93. Detection, 2-Event Class and Port Turn On
TPS2388 app_04_LUSC24.gifFigure 95. 2-Event Class and Port Turn On
