4.1 Introduction

The device can change the values of ChargingVoltage() and ChargingCurrent() based on Temperature() and Cell Voltage1..2(). Its flexible charging algorithm is JEITA-compatible and can also meet other specific cell manufacturer charge requirements. The ChargingStatus() register shows the state of the charging algorithm.
