6.3 Gas Gauge Modes

Resistance updates take place only in DISCHARGE mode, while OCV and QMax updates only take place in RELAX mode. Entry and exit of each mode is controlled by data flash parameters in the subclass Gas Gauging: Current Thresholds section. When the device is determined to be in RELAX mode and OCV is taken, the GaugingStatus[REST] flag is set. In RELAX mode or DISCHARGE mode, the DSG flag in BatteryStatus is set.

GUID-646CC2C1-1EFA-4839-9DFB-63E16E4178AB-low.gifFigure 6-1 Gas Gauge Operating Modes

CHARGE mode is exited and RELAX mode is entered when Current goes below Quit Current for a period of Chg Relax Time. DISCHARGE mode is entered when Current goes below (–)Dsg Current Threshold. DISCHARGE mode is exited and RELAX mode is entered when Current goes above (–)Quit Current threshold for a period of Dsg Relax Time. CHARGE mode is entered when Current goes above Chg Current Threshold.

GUID-D4EA36DD-4130-4E08-B82B-33EC4BE54855-low.svg Figure 6-2 Gas Gauge Operating Mode Example
