7.6 Power MOSFET Drain-Source Voltage

Figure 7-9 and Figure 7-10 show the low-side and high-side MOSFET drain-source voltage (VDS) at 40-A load. The voltage is measured with 1-GHz bandwidth and at the solder mask openings near the U1_P1 IC using a 1-GHz differential probe.

GUID-EB350D97-247B-4D43-AA00-2BA519FD800D-low.gifFigure 7-9 Low-Side MOSFET VDS
GUID-31E55C71-F5E7-4CDC-889E-3B0D57B61305-low.gifFigure 7-10 High-Side MOSFET VDS
