8.5.2 Layout Example

Figure 8-14 to Figure 8-16 provide examples of the critical traces routed on the device evaluation module (EVM). Figure 8-17 provides an example printed circuit board (PCB) layer stackup.

GUID-D91217FE-F7CB-4E41-9C1A-7EF1F09C27C0-low.gifFigure 8-14 Top Layer Routing: Analog Inputs, CLK and SYSREF, DA0-3, DB0-3
GUID-662F7C35-2988-4892-8B59-3D4FAE2A9BEA-low.gifFigure 8-15 GND1 Cutouts to Optimize Impedance of Component Pads
GUID-4D3DF982-AED2-4F45-9AA1-FD6BE160D100-low.gifFigure 8-16 Bottom Layer Routing: Additional CLK Routing, DA4-7, DB4-7
GUID-0F50AE7A-5D5D-4DE0-9B24-EA659839ECB4-low.gifFigure 8-17 Example PCB Stackup
