10.1.4.3 Soft-Start Capacitor

A capacitor connected between SS/TR pin and GND sets user programmable start-up slope of the output voltage. A constant current source provides typically 2.5 µA to charge the external capacitance. The capacitor required for a given soft-start ramp time is given by:

Equation 14. GUID-C94AC8A6-74DC-4437-88CB-4B5B5B1ABBCB-low.gif

where

  • CSS is the capacitance required at the SS/TR pin and
  • tSS is the desired soft-start ramp time

The fastest achievable typical ramp time is 150 µs even if the external Css capacitance is lower than 680 pF or the pin is open.
