1.4 Typical Application

The following diagram illustrates a typical rear seat entertainment application that utilizes the DS90UH928Q deserializer and a compatible serializer (DS90UH925Q or DS90UH927Q). The DS90UH928Q accepts FPD-Link III data transported over an automotive-grade STP cable and deserializes the data stream into video, audio, and control information intended for a display and other local peripherals.

DS90UB928QEVM Typical Application/Evaluation ConfigurationFigure 1-1 Typical Application/Evaluation Configuration
