6.11.6 RX Typical Characteristics 4.9GHz

Typical values at TA = +25°C, ADC Sampling Rate = 2949.12 GHz. Default conditions: output sample rate = 491.52MSPS (decimate by 6), PLL clock mode with fREF = 491.52MHz, AIN = –3 dBFS, DSA setting = 4 dB.

With matching, normalized to power at 4.9GHz for each DSA setting
Figure 6-173 RX Inband Gain Flatness, fIN = 4900 MHz
With 4.9 GHz matching, normalized to phase at 25°C
Figure 6-175 RX Input Phase vs Temperature and DSA at fOUT = 4.9 GHz
With 4.9 GHz matching
Differential Amplitude Error = PIN(DSA Setting – 1) – PIN(DSA Setting) + 1
Figure 6-177 RX Calibrated Differential Amplitude Error vs DSA Setting at 4.9 GHz
With 4.9 GHz matching
Integrated Amplitude Error = PIN(DSA Setting) – PIN(DSA Setting = 0) + (DSA Setting)
Figure 6-179 RX Calibrated Integrated Amplitude Error vs DSA Setting at 4.9 GHz
With 4.9 GHz matching
Differential Phase Error = PhaseIN(DSA Setting – 1) – PhaseIN(DSA Setting)
Figure 6-181 RX Calibrated Differential Phase Error vs DSA Setting at 4.9 GHz
With 4.9 GHz matching
Integrated Phase Error = Phase(DSA Setting) – Phase(DSA Setting = 0)
Figure 6-183 RX Calibrated Integrated Phase Error vs DSA Setting at 4.9 GHz
With 4.9 GHz matching, 12.5-MHz offset from tone
Figure 6-185 RX Noise Spectral Density vs Temperature at 4.9 GHz
With 4.9 GHz matching, 12.5-MHz offset from tone
Figure 6-187 RX Noise Spectral Density vs Input Amplitude and Channel at 4.9 GHz
With 4.9 GHz matching, tone spacing = 20 MHz, DSA = 4 dB
Figure 6-189 RX IMD3 vs Input Level and Temperature at 4.9 GHz
With 4.9 GHz matching, measured after HD2 trim, DDC bypass mode (TI only mode for characterization)
Figure 6-191 RX HD2 vs DSA Setting and Channel at 4.9 GHz
With 4.9 GHz matching, measured after HD2 trim, DDC bypass mode (TI only mode for characterization)
Figure 6-193 RX HD2 vs Input Level and Temperature at 4.9 GHz
With 4.9 GHz matching, DDC bypass mode (TI only mode for characterization)
Figure 6-195 RX HD3 vs DSA Setting and Temperature at 4.9 GHz
With 4.9 GHz matching, DDC bypass mode (TI only mode for characterization)
Figure 6-197 RX HD3 vs Input Level and Temperature at 4.9 GHz
With 4.9 GHz matching
Figure 6-199 RX Non-HD2/3 vs DSA Setting at 4.9 GHz
With 4.9 GHz matching, 12.5-MHz offset, all supplies at MIN, TYP, or MAX recommended operating voltages
Figure 6-201 RX Noise Spectral Density vs Supply and Channel at 4.9 GHz
With 4.9 GHz matching, normalized to fullscale at 25°C for each channel
Figure 6-174 RX Input Fullscale vs Temperature and Channel at 4.9 GHz
With 4.9 GHz matching
Differential Amplitude Error = PIN(DSA Setting – 1) – PIN(DSA Setting) + 1
Figure 6-176 RX Uncalibrated Differential Amplitude Error vs DSA Setting at 4.9 GHz
With 4.9 GHz matching
Integrated Amplitude Error = PIN(DSA Setting) – PIN(DSA Setting = 0) + (DSA Setting)
Figure 6-178 RX Uncalibrated Integrated Amplitude Error vs DSA Setting at 4.9 GHz
With 4.9 GHz matching
Differential Phase Error = PhaseIN(DSA Setting – 1) – PhaseIN(DSA Setting)
Figure 6-180 RX Uncalibrated Differential Phase Error vs DSA Setting at 4.9 GHz
With 4.9 GHz matching
Integrated Phase Error = Phase(DSA Setting) – Phase(DSA Setting = 0)
Figure 6-182 RX Uncalibrated Integrated Phase Error vs DSA Setting at 4.9 GHz
With 4.9 GHz matching, fIN = 4910 MHz, AIN= –3 dBFS
Figure 6-184 RX Output FFT at 4.9 GHz
With 4.9 GHz matching, DSA Setting = 12 dB, 12.5-MHz offset from tone
Figure 6-186 RX Noise Spectral Density vs Input Amplitude and Temperature at 4.9 GHz
With 4.9 GHz matching, each tone –7 dBFS, tone spacing = 20 MHz
Figure 6-188 RX IMD3 vs DSA Setting and Temperature at 4.9 GHz
With 4.9 GHz matching, tone spacing = 20 MHz, DSA = 12 dB
Figure 6-190 RX IMD3 vs Input Level and Temperature at 4.9 GHz
With 4.9 GHz matching, measured after HD2 trim, DDC bypass mode (TI only mode for characterization)
Figure 6-192 RX HD2 vs DSA and Temperature at 4.9 GHz
With 4.9 GHz matching, DDC bypass mode (TI only mode for characterization)
Figure 6-194 RX HD3 vs DSA Setting and Channel at 4.9 GHz
With 4.9 GHz matching, DDC bypass mode (TI only mode for characterization)
Figure 6-196 RX HD3 vs Input Level and Channel at 4.9 GHz
With 4.9 GHz matching, decimate by 3
Figure 6-198 RX In-Band SFDR (±400 MHz) vs Input Amplitude and Channel at 4.9 GHz
With 4.9 GHz matching, –7 dBFS each tone, 20-MHz tone spacing, all supplies at MIN, TYP, or MAX recommended operating voltages
Figure 6-200 RX IMD3 vs Supply and Channel at 4.9 GHz
