9.2.1.3 Internal GCLK Frequency

The internal GCLK frequency is configured by the Frequency Multiplier (FREQ_MUL) and is determined by the PWM resolution. The GCLK frequency can be calculated by the below equations:

Equation 3. GUID-41EEC148-44DB-451A-8919-DC4C06B22881-low.gif

where

  • frefresh_rate means the refresh rate
  • fframe_rate means the frame rate
  • K means the PWM resolution
  • Nsub_period means the sub-period numbers within one frame
  • NGCLK_seg means the GCLK number per segment (line switch time excluded)
  • fGCLK means GCLK frequency
  • TSW means line switching time
  • Nscan_line means the scan line number
  • Tblank means the blank time in one frame, equals to 0 in ideal configuration
  • GSmax means the maximum grayscale that the device can output in one frame

Table 9-2 gives the values based on the system configuration and equation.

Table 9-2 LP5890 Design Parameters for GCLK Frequency Calculation
DESIGN PARAMETEREXAMPLE VALUE
Nsub_period32
Nscan_line30
TSW1.5 µs
Tblank0
NGCLK_seg512
GSmax16383
fGCLK71.3 MHz

Considering SCLK frequency and FREQ_MUL, the SCLK can be 27.7 MHz and FREQ_MUL can be 0010b. So the GCLK will be 83.1 MHz.
