9.2.1.3 Application Curves

TPS3870-Q1 App2-Latch-Sense-Ramp-Up.gif
VSENSE ramp from 0 V to 1.4V, VDD = 3.3 V, VCT = 0 V
VRESET = VDD = 3.3 V
Figure 26. TPS3870-Q1 SENSE Ramp Latch Function
TPS3870-Q1 App2-Latch-Vdd-RAmp.gif
VDD ramp up from 0 V to 3.3 V , VSENSE = 1.2 V, CT = 0 V
VRESET = VDD = 3.3 V
Figure 28. TPS3870-Q1 VDD Ramp Latch Function
TPS3870-Q1 App2-Latch-VCT-Unlatch.gif
VCT biased at least to 1.15 V , VSENSE = 1.2 V
VRESET = VDD = 3.3 V
Figure 27. TPS3870-Q1 CT Bias Unlatch Function
