7 Parameter Measurement Information

TS3A24157 on_resis_cds208_v2.gif Figure 10. ON-State Resistance
TS3A24157 off_leak_cds208_v2.gif
INC(OFF), INC(PWROFF), INO(OFF), INO(PWROFF), ICOM(OFF), ICOM(PWROFF)
Figure 11. OFF-State Leakage Current
TS3A24157 on-leak_cds208_v2.gif
ICOM(ON), INC(ON), INO(ON)
Figure 12. ON-State Leakage Current
TS3A24157 capacitance_cds208_v2.gif
CI, CCOM(ON), CNC(OFF), CNO(OFF), CNC(ON), CNO(ON)
Figure 13. Capacitance
TS3A24157 turn_on_off_cds208_v2.gif
1. All input pulses are supplied by generators having the following characteristics:
  • PRR ≤ 10 MHz
  • ZO = 50 Ω
  • tr < 5 ns
  • tf < 5 ns
2. CL includes probe and jig capacitance.
Figure 14. Turnon and Turnoff Time
TS3A24157 br_before_m_cds208_v2.gif
1. All input pulses are supplied by generators having the following characteristics:
  • PRR ≤ 10 MHz
  • ZO = 50 Ω
  • tr < 5 ns
  • tf < 5 ns
B. CL includes probe and jig capacitance.
Figure 15. Break-Before-Make Time
TS3A24157 bandwidth_cds208_v2.gif Figure 16. Bandwidth
TS3A24157 off_isol_cds208_v2.gif Figure 17. OFF Isolation
TS3A24157 crosstalk_cds208_v2.gif Figure 18. Crosstalk
TS3A24157 charge_inj_cds208_v2.gif
1. All input pulses are supplied by generators having the following characteristics:
  • PRR ≤ 10 MHz
  • ZO = 50 Ω
  • tr < 5 ns
  • tf < 5 ns
2. CL includes probe and jig capacitance.
Figure 19. Charge Injection
TS3A24157 har_dist_cds208_v2.gif
1. CL includes probe and jig capacitance.
Figure 20. Total Harmonic Distortion
