JAJSF94F July 2015 – May 2018 SN65DP159 , SN75DP159
PRODUCTION DATA.
TMDS DATA RATE (Gbps) | H (Tbit) | V (mV) |
3.4 < DR < 3.712 | 0.6 | 335 |
3.712 < DR < 5.94 | –0.0332Rbit2 + 0.2312Rbit + 0.1998 | –19.66Rbit2 + 106.74Rbit + 209.58 |
5.94 ≤ DR ≤ 6.0 | 0.4 | 150 |
